Data Director for LS Central is used to transfer data back and forth between Franchiser and Franchisee.
Data is imported into the Inbound Buffer, the Inbound Buffer is then processed and Inbound Buffer data is error checked. If an error occurs according to Processing Setup, the status of the record is set as STOP. If there is no error, the record is processed.
Processed Inbound Buffer records are archived and a processed confirmation message is put in the Outbound Buffer.
Sales and Purchase Orders - Diagrams
When a Franchisee sends a Purchase Order to Franchiser
The diagram shows what happens in the system when a Franchisee sends a Purchase Order to a Franchiser.
When a Franchiser sends a Sales Order to Franchisee
The diagram shows what happens in the system when a Franchiser sends a Sales Order to a Franchisee.
